Specifications

CPU: Cortex M3 72MHz

Memory: 128 KB Flash + 20 KB RAM

Dimension: 36 x 65 x 18 (mm)

Certifications: CE, UKCA, KC, FCC, RoHS, REACH, WEEE

RS-485: 1 ch (OSDP V2 Compliant)

TTL Input: 2 ch

Relay: 1 relay

Power: 12 VDC, Current: Max. 0.5 A
